- 24 ports with full Power over Ethernet Plus (PoE+) capability
- Fixed redundant fans for enhanced reliability
- 4 × 1G fixed uplinks for flexible connectivity
- Network Essentials software for seamless operations
- Default primary AC power supply: PWR-C5-600WAC
- Stacking bandwidth of up to 80 Gbps for improved scalability
- Supports up to 16,000 MAC addresses
- IPv4 routing capacity of 11,000 routes (8,000 direct, 3,000 indirect)
- IPv6 routing support with 1,500 entries
- Multicast routing scale of 1,000 entries
- 1,000 QoS scale entries for traffic optimization
- 1,500 Access Control List (ACL) scale entries for security policies
- 6 MB packet buffer for 24- or 48-port Gigabit Ethernet models
- Full Flexible NetFlow (FNF) with up to 16,000 flow entries
- Equipped with 2 GB DRAM and 4 GB Flash storage
- VLAN support for up to 1,024 VLAN IDs
- Total of 512 Switched Virtual Interfaces (SVIs)
- Jumbo frame support up to 9,198 bytes
- 56 Gbps switching capacity for high-performance networking
- Forwarding rate of 83.33 Mpps for efficient data processing
- Mean time between failures (MTBF) of 392,210 hours for long-term reliability
| Specification | C9200L-24P-4G-E |
|---|
| Downlinks (10/100/1000 or PoE+ ports) | 24 ports full PoE+ |
| Uplink Configuration | 4 × 1G fixed uplinks |
| Default Primary AC Power Supply | PWR-C5-600WAC |
| Fans | Fixed redundant |
| Software | Network Essentials |
| Chassis Dimensions | 1.73 x 17.5 x 11.3 in (4.4 x 44.5 x 28.8 cm) |
| Weight | 10.38 pounds |
| Virtual Networks | 1 |
| Stacking Bandwidth | 80 Gbps |
| Total MAC Addresses | 16,000 |
| Total IPv4 Routes (ARP + Learned Routes) | 11,000 (8,000 direct, 3,000 indirect) |
| IPv4 Routing Entries | 3,000 |
| IPv6 Routing Entries | 1,500 |
| Multicast Routing Scale | 1,000 |
| QoS Scale Entries | 1,000 |
| ACL Scale Entries | 1,500 |
| Packet Buffer per SKU | 6 MB (for 24- or 48-port Gigabit Ethernet models) |
| Flexible NetFlow (FNF) Entries | 16,000 flows (on 24- and 48-port Gigabit Ethernet models) |
| DRAM | 2 GB |
| Flash | 4 GB |
| VLAN IDs | 1,024 |
| Total Switched Virtual Interfaces (SVIs) | 512 |
| Jumbo Frames | 9,198 bytes |
| Wireless Bandwidth per Switch | N/A |
| Switching Capacity | 56 Gbps |
| Forwarding Rate | 83.33 Mpps |
| Mean Time Between Failures (MTBF) | 392,210 hours |
